產(chǎn)品詳情
每小時處理能力500-4500噸， 定制設(shè)備請聯(lián)系我們
Specification
| Equipment model | Unit |
CSL 500 |
CSL 800 |
CSL 1200 |
CSL 1800 |
CSL 2600 |
CSL 3200 |
CSL 4000 |
CSL 4500 |
||
| Production capacity | t/h | 500 | 800 | 1200 | 1800 | 2600 | 3200 | 4000 | 4500 | ||
| Material characteristics: | Applicable materials | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | |||||||||
| Density | t/m3 | 0.5-2.5 | |||||||||
| Particle size | mm | 0-300 | |||||||||
| Traveling speed | Work | m/min | 10 | ||||||||
| Dispatching vehicle | 30 | ||||||||||
| Cantilever crane pitching | Work | ° | 0～+16 | ||||||||
| Non-working | ° | 70 | |||||||||
| Speed | r/min | 2/4/6/8 | |||||||||
| Telescopic speed of cantilever crane | r/min | 6(cantilever crane angle0～+16)/3(cantilever crane angle0～+35) | |||||||||
| Chute tube speed | Rotation | m/min | 0～6 | ||||||||
| Stretch | 1 | ||||||||||
| Conveyer | Belt speed | m/s | 1.25-4 | ||||||||
| Bandwidth | mm | 1.25-4 | |||||||||
| Rail gauge | m | 650-2400 | |||||||||
| Maximum wheel load | KN | 250-350 | |||||||||
| Recommended steel track | P50-Q80 | ||||||||||
| Power supply mode | Cable drum/safety sliding contact line | ||||||||||
| Contact mode | Cable drum/safety sliding contact line/wireless | ||||||||||
| Control mode | PLC program control, manual and single action | ||||||||||
